Electromagnetic Pump Testing System for Flow, Pressure & Performance Evaluation | Automated Pump Testing Equipment with Data Logging & Safety Protection

Electromagnetic Pump Testing System for Flow, Pressure & Performance Evaluation | Automated Pump Testing Equipment with Data Logging & Safety Protection

نام تجاری: HongCe
شماره مدل: HJ-WPVT-001
مقدار تولیدی: 1 مجموعه
قیمت: قابل مذاکره
شرایط پرداخت: L/C، T/T
توانایی عرضه: 1 ست در هر 45 روز
اطلاعات دقیق
محل منبع:
چین
گواهی:
Calibration certificate(cost additional)
نمایش منحنی:
منحنی جریان-فشار / بازده
کنترل دما:
محیط تا 60 درجه سانتی گراد
حفاظت ایمنی:
فشار بیش از حد / جریان بیش از حد / توقف اضطراری
حالت چرخه تست:
دستی / اتوماتیک
ایستگاه تست:
تک یا چند ایستگاهی (اختیاری)
مواد سیستم:
فولاد ضد زنگ + قاب صنعتی
جزئیات بسته بندی:
تخته سه لا
برجسته کردن:

electromagnetic pump testing system,automated pump testing equipment with data logging,pump testing system for flow pressure

,

automated pump testing equipment with data logging

,

pump testing system for flow pressure

توضیحات محصول
Electromagnetic Pump Testing System
Comprehensive automated testing equipment for evaluating electromagnetic pump performance, flow rates, pressure capabilities, and operational efficiency with integrated data logging and safety protection systems.
Ensure your electromagnetic pumps perform reliably under real-world conditions with precision testing that validates flow characteristics, pressure handling, efficiency metrics, power consumption, and operational stability.
Key Features
  • High-precision sensors for flow, pressure, and electrical parameters
  • Stable test loop with electromagnetic pump load simulation
  • Automated test control and data acquisition
  • Real-time curve display and historical data storage
  • Modular design for easy maintenance and upgrades
  • Safety protection: over-pressure, over-current, emergency stop
Technical Specifications
Test System Type Electromagnetic Pump Testing System
Test Medium Water (customizable)
Flow Range 0.1 – 30 L/min (customizable)
Pressure Range 0 – 1.6 MPa
Pressure Accuracy ±0.5% F.S
Flow Accuracy ±1% F.S
Power Supply AC 220V / 50Hz (customizable)
Control Mode PLC + Touch Screen
Data Acquisition Real-time data logging
Compatible Test Objects
  • Electromagnetic pumps
  • Miniature electric pumps
  • Circulating pumps
  • Liquid transfer pumps
  • Cooling system pumps
  • Industrial micro pumps
International Compliance Standards
  • ISO 9906 – Rotodynamic pumps – Hydraulic performance acceptance tests
  • IEC 60034-1 – Rotating electrical machines – Rating and performance
  • IEC 60204-1 – Safety of machinery – Electrical equipment of machines
  • GB/T 3216 – Acceptance tests for pumps – Class 1, 2 and 3
  • GB/T 12785 – Test methods for electromagnetic pumps
  • GB/T 17626 – Electromagnetic compatibility (EMC) test reference
Frequently Asked Questions
Can this system test different pump models?
Yes. The system supports parameter adjustment and fixture customization for different pump sizes and performance ranges.
Can you customize the flow and pressure range?
Yes. HongCe provides tailored configurations based on your specific testing requirements.
Is test data exportable?
Yes. Data can be exported via USB or network connectivity for comprehensive reporting and traceability.
Can it be integrated into a production line?
Yes. The system supports End-of-Line testing integration and MES data interface capabilities.
Do you provide on-site training?
Yes. Both remote and on-site training services are available to ensure optimal system operation.
